New Way® offers two-piece, aluminum flexure mounts specifically designed for the mounting of Vacuum Preloaded Air Bearings (VPLs). New Way flexure mounts provide bi-directional stiffness, a low pivot point, and infinitesimal angular adjustment.

  • Easy to install
  • Limitless adjustments
  • Bi-directional stiffness
  • Compatible with all Vacuum Preloaded Bearings
  • Aluminum construction
  • Low pivot point

Applications

New Way flexure mounts are designed to accommodate VPLs for use in precision linear motion applications.

Semiconductor
  • VPLs supporting wafer processing can easily be implemented and adjusted as needed.
  • Parallelism is obtained through flexure mounts without costly precision machining of a plate.
Area of Interest (AOI) Inspection
  • Flexure mount provides directional stiffness without hysteresis providing greater confidence in the precision required while inspecting AOIs.
Test and Measurement Suites
  • Precision products demand even more from their test equipment. VPLs with flexure mounts deliver precision and are easy to adjust for calibrations and assembly changes.

Product Line

New Way flexure mounts are available in 40 or 80 thread and are compatible with all standard VPLs.


S8010F01S8010F01 - 0.375 - 80 Thread Flexure Mounts
flexure mounts
S8010F01S8010F01 - 0.375 - 80 Thread Flexure Mounts

S8010F02S8010F02 - 0.375 - 40 Thread Flexure Mounts
flexure mounts
S8010F02S8010F02 - 0.375 - 40 Thread Flexure Mounts



Questions

If you have questions about using our flexure mounts with VPLs, please contact our team of engineer consultants today!
