SS-55SS-55 – 55mm “T” Series Air Spindle



55mm "T" Series Air Spindle
SS-55SS-55

The “T-Series” Spindles are an ideal assembly for building frictionless rotary motion, New Way spindles provide a fast, effective, precision out of the box solution. In either square or round stator configurations, this new product line gives you all the differential advantages of New Way porous media technology.

For Specifications contact New Way Technical Support at: 610.364.3465.

Units: US METRIC
TitleSpecifications
Size2.2 in55 mm
SKUSS-55SS-55
Input Pressure60psi0.41 MPa
Axial Load21 lbs91 (N)
Radial Load9 lbs41 (N)
Axial and Radial Error Motion3.9 μin0.1 (uM)
Max. Speed21739 (RPM)21739 (RPM)
Average No Load Flow23.5 SCFH11.1 NLPM

Attachments:
